AcuSeek NEW HOT
add compare icon

AH-STI-DSIR30-H2EG-B，Scanning imaging radar

  • Perform high-precision imaging of the target through two-dimensional axial 360° scanning.
  • The antenna beam angle is small, the measurement is more accurate and the detection distance is longer.
  • The maximum imaging radius is 30 meters.
  • Support outputting material surface and volume when combined with imaging host. The error of volume calculation is ≤ 3%.
  • Equipped with high-precision attitude sensor for self-correction of inclination.
  • Standard flange connection.
  • Works around the clock, unaffected by rain, dust, light, temperature and other environmental factors.
View Less
View more
Sales Inquiry

Available models:

STI-DSIR30-H2EG-B
View more View Less
STI-DSIR30-H2EG-B

Specification

  • Radar
  • Working Frequency80GHz
  • Sweep Bandwidth2.37GHz
  • Distance Measurement Accuracy±5mm
  • Angle Accuracy3°
  • Measurement PrincipleMillimeter wave
  • Point Clouds Density400Point/Frame
  • Point Clouds Quantity≤12Ten thousand
  • Scanning Cycle100ms
  • Supported Material TypeNon-metallic solid bulk material
  • Scan Rate50ms
  • Beam Angle3°
  • Modulation WaveformFMCW
  • Horizontal Scanning Angle360°
  • Vertical Scanning Angle180°
  • Distance Resolution5.9cm
  • Angle Resolution3°
  • Measurement Distance30m
  • Function
  • Data Refresh Time30s（Configurable）
  • Interface
  • Communication InterfaceRS485/Ethernet/4~20mA/relay
  • General
  • Dimensions366mm×194mm（英文）
  • ProtectionIP67
  • 6500g
  • Application ScenarioSilo
  • MaterialAluminum/Plastic
  • Operating Condition-40℃~85℃
  • Package Dimensions600X500X480mm
  • Power18V~32V DC
  • With Package Weight17770g
  • Packing List
  • Power Adapter1 piece
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Radar
Working Frequency
80GHz
Sweep Bandwidth
2.37GHz
Distance Measurement Accuracy
±5mm
Angle Accuracy
3°
Measurement Principle
Millimeter wave
Point Clouds Density
400Point/Frame
Point Clouds Quantity
≤12Ten thousand
Scanning Cycle
100ms
Supported Material Type
Non-metallic solid bulk material
Scan Rate
50ms
Beam Angle
3°
Modulation Waveform
FMCW
Horizontal Scanning Angle
360°
Vertical Scanning Angle
180°
Distance Resolution
5.9cm
Angle Resolution
3°
Measurement Distance
30m
Function
Data Refresh Time
30s（Configurable）
Interface
Communication Interface
RS485/Ethernet/4~20mA/relay
General
Dimensions
366mm×194mm（英文）
Protection
IP67
6500g
Application Scenario
Silo
Material
Aluminum/Plastic
Operating Condition
-40℃~85℃
Package Dimensions
600X500X480mm
Power
18V~32V DC
With Package Weight
17770g
Packing List
Power Adapter
1 piece
