AcuSeek NEW HOT
add compare icon

IP Video Intercom Kit

  • 4MP higher resolution with 150° viewing angle
  • 2 locks control
  • Multiple unlocking methods: Face / Card / Bluetooth / App
  • Video recording and playback via indoor station or door station
  • Standard PoE power supply
  • Including: DS-KH6350-WTE1 x1, DS-KV8114-NWE1 x1, 4 port PoE switch x1, DS-KABV8114-RS/S x1, PSU × 1, Administrator Card x1, Key fob x 5

View Less
View more
Data Sheet
Sales Inquiry

Available models:

DS-KIS621-S
View more View Less
DS-KIS621-S
Data Sheet

Specification

  • Door station/System parameters
  • Operation systemLinux
  • ProcessorEmbedded high performance processor
  • Memory/
  • RAM1 GB
  • ROM4 GB
  • Door station/Video parameters
  • Supplement lightIR light, up to 3 m
  • ResolutionMain stream: 4MP(2688x1520P), 2MP(1920x1080P), 1MP(1280x720P) Sub stream: 2MP(1920x1080P), 1MP(1280x720P), 0.3MP(640x480P)
  • Lens1
  • FOVHorizontal: 150°; Vertical: 105°
  • Video compression standardH.264; H.265; MJPEG
  • Door station/Audio parameters
  • Volume adjustmentAdjustable
  • Audio Performance50cm, 85dB
  • Door station/Capacity parameters
  • User capacity5000
  • Card capacity25000
  • Door station/Network parameters
  • Network protocolTCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, IPv4, IPv6, UDP, WebSocket, WebSockets，ONVIF, SIP v2 (RFC3261)
  • Wi-Fi2.4GHz
  • BluetoothSupported
  • Wi-Fi ProtocolIEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax
  • Wi-Fi TypeWiFi 6
  • Door station/Authentication parameters
  • Card reading frequency13.56 MHz
  • Card TypeM1 Card
  • Card Reading Distance3 cm
  • Authentication modeFace;Card;Bluetooth;Mobile APP;Indoor Station
  • Door station/Application
  • Mobile APPHik-Connect
  • Motion DetectionSupport
  • PlaybackSupport
  • Call ElevatorSupport
  • Smart Features1. Sound Classification Detection: Scream, Glass Breaking Sound, Crying Sound, Gunshot Recommended Detection Distance: ＜ 3 m 2. Portrait Centered 3. Perimeter Detection: Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection Recommended Detection Distance: ＜ 10 m Supports Person and Vehicle Target Detection 4. Fall Down Detection Recommended Detection Distance: ＜ 5 m 5. Target Microphone Pickup Range: Forward 60° Sector Area Recommended Detection Distance: 0.5 m ~ 1 m 6. Smart Noise Reduction Supports Common Steady-State and Non-Steady-State Street Noises Noise Reduction Level: > 15 dB
  • Door station/Device interfaces
  • Network interface1 RJ-45, 10/100 Mbps self-adaptive
  • Exit button2
  • Lock control2 relay, Max. 30 VDC 1 A
  • RS-4851
  • Door contact input2
  • Alarm input4(includeExit button and Door contact input)
  • Alarm output0
  • TAMPER1
  • TF cardSupport TF card, up to 128 G
  • Supported TF FormatFAT32;exFAT
  • Door station/General
  • Button4 physical button(s)
  • Indicator3
  • Power consumptionWith Lock: < 20 W Without Lock: < 14 W
  • Working temperature-40 °C to 60 °C (-40 °F to 140 °F)
  • Working humidity10% to 90% (no-condensing)
  • Application environmentOutdoor
  • Dimension (W × H × D)202.6 mm × 95.6 mm × 28.5 mm (7.98" × 3.76" × 1.12")
  • Protective levelIP66, IK08
  • InstallationSurface mounting & Flush mounting(With braket)
  • MaterialRear Shell Material: Plastic Front Shell: Aluminum Alloy & Plastic Frame: Aluminum Alloy Viewing Window Panel Material: Glass
  • Power supply12 VDC, 2 A,IEEE 802.3 at, standard PoE
  • LanguageEnglish, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
  • Power Supply OutputMax. 12 VDC, 500mA
  • Indoor station/Audio parameters
  • Audio input1 built-in omnidirectional microphone
  • Audio output1 built-in loudspeaker
  • Audio qualityNoise suppression and echo cancellation
  • Audio compression standardG.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
  • Audio compression bitrate16~64Kps
  • Indoor station/Network parameters
  • Wired network 1 RJ-45, 10/100 Mbps self-adaptive
  • Wireless network2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
  • Network protocolTCP/IP, SIP, RTSP
  • Indoor station/Device interfaces
  • RS-4851 RS-485 (Half duplex)
  • Alarm input8-ch alarm inputs
  • Relay output2
  • TF cardSupport TF card, up to 128 G
  • Indoor station/General
  • Power consumption≤ 5 W
  • Power supply12 VDC, 1 A,IEEE802.3af, Standard PoE
  • Working temperature-10 °C to 50 °C (14 °F to 122 °F)
  • Working humidity10% to 90%
  • Dimension (L x W x H)178.4 mm × 126.4 mm × 21.8 mm (7.02" × 4.98" × 0.86")
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Door station/System parameters
Operation system
Linux
Processor
Embedded high performance processor
Memory
/
RAM
1 GB
ROM
4 GB
Door station/Video parameters
Supplement light
IR light, up to 3 m
Resolution
Main stream: 4MP(2688x1520P), 2MP(1920x1080P), 1MP(1280x720P) Sub stream: 2MP(1920x1080P), 1MP(1280x720P), 0.3MP(640x480P)
Lens
1
FOV
Horizontal: 150°; Vertical: 105°
Video compression standard
H.264; H.265; MJPEG
Door station/Audio parameters
Volume adjustment
Adjustable
Audio Performance
50cm, 85dB
Door station/Capacity parameters
User capacity
5000
Card capacity
25000
Door station/Network parameters
Network protocol
TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, IPv4, IPv6, UDP, WebSocket, WebSockets，ONVIF, SIP v2 (RFC3261)
Wi-Fi
2.4GHz
Bluetooth
Supported
Wi-Fi Protocol
IEEE802.11b;IEEE802.11g;IEEE802.11n;IEEE802.11ax
Wi-Fi Type
WiFi 6
Door station/Authentication parameters
Card reading frequency
13.56 MHz
Card Type
M1 Card
Card Reading Distance
3 cm
Authentication mode
Face;Card;Bluetooth;Mobile APP;Indoor Station
Door station/Application
Mobile APP
Hik-Connect
Motion Detection
Support
Playback
Support
Call Elevator
Support
Smart Features
1. Sound Classification Detection: Scream, Glass Breaking Sound, Crying Sound, Gunshot Recommended Detection Distance: ＜ 3 m 2. Portrait Centered 3. Perimeter Detection: Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection Recommended Detection Distance: ＜ 10 m Supports Person and Vehicle Target Detection 4. Fall Down Detection Recommended Detection Distance: ＜ 5 m 5. Target Microphone Pickup Range: Forward 60° Sector Area Recommended Detection Distance: 0.5 m ~ 1 m 6. Smart Noise Reduction Supports Common Steady-State and Non-Steady-State Street Noises Noise Reduction Level: > 15 dB
Door station/Device interfaces
Network interface
1 RJ-45, 10/100 Mbps self-adaptive
Exit button
2
Lock control
2 relay, Max. 30 VDC 1 A
RS-485
1
Door contact input
2
Alarm input
4(includeExit button and Door contact input)
Alarm output
0
TAMPER
1
TF card
Support TF card, up to 128 G
Supported TF Format
FAT32;exFAT
Door station/General
Button
4 physical button(s)
Indicator
3
Power consumption
With Lock: < 20 W Without Lock: < 14 W
Working temperature
-40 °C to 60 °C (-40 °F to 140 °F)
Working humidity
10% to 90% (no-condensing)
Application environment
Outdoor
Dimension (W × H × D)
202.6 mm × 95.6 mm × 28.5 mm (7.98" × 3.76" × 1.12")
Protective level
IP66, IK08
Installation
Surface mounting & Flush mounting(With braket)
Material
Rear Shell Material: Plastic Front Shell: Aluminum Alloy & Plastic Frame: Aluminum Alloy Viewing Window Panel Material: Glass
Power supply
12 VDC, 2 A,IEEE 802.3 at, standard PoE
Language
English, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese
Power Supply Output
Max. 12 VDC, 500mA
Indoor station/Audio parameters
Audio input
1 built-in omnidirectional microphone
Audio output
1 built-in loudspeaker
Audio quality
Noise suppression and echo cancellation
Audio compression standard
G.711u、G.711a、Opus、AAC-LD、AAC-LC、G.726、G.722.1
Audio compression bitrate
16~64Kps
Indoor station/Network parameters
Wired network
1 RJ-45, 10/100 Mbps self-adaptive
Wireless network
2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
Network protocol
TCP/IP, SIP, RTSP
Indoor station/Device interfaces
RS-485
1 RS-485 (Half duplex)
Alarm input
8-ch alarm inputs
Relay output
2
TF card
Support TF card, up to 128 G
Indoor station/General
Power consumption
≤ 5 W
Power supply
12 VDC, 1 A,IEEE802.3af, Standard PoE
Working temperature
-10 °C to 50 °C (14 °F to 122 °F)
Working humidity
10% to 90%
Dimension (L x W x H)
178.4 mm × 126.4 mm × 21.8 mm (7.02" × 4.98" × 0.86")
