4MP DeepinView Separated Network Camera

Name: 4MP DeepinView Separated Network Camera
Brand: Hikvision
Availability: InStock
Rating: 5.0 (1 reviews)

High quality imaging with 4 MP resolution
Clear imaging against strong back light due to WDR technology
Supports Hikvision Embedded Open Platform (HEOP) and importing third party applications
Supports 4 Tops computing power, 150 MB system memory, 2150 MB smart RAM, and 1 GB eMMC storage for sharing resources
Audio and alarm interface available

View Less

DS-2CD6445G3-C2W

DS-2CD6445G3-C2

Data Sheet

Available models:

DS-2CD6445G3-C2W

View more View Less

Available models:

DS-2CD6445G3-C2

View more View Less

DS-2CD6445G3-C2(W)

Specification
Resources
Accessories

Data Sheet

กล้อง
Image Sensor 1/2.7" Progressive Scan CMOS
Max. Resolution 2688 × 1520
Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON)
Shutter Time 1 s to 1/100,000 s

Lens
Focal Length & FOV L30 model: 2 mm, Horizontal FOV:128°, Vertical FOV:75°, Diagonal FOV:147° 2.8 mm, Horizontal FOV:104°, Vertical FOV:58°, Diagonal FOV:122° 4 mm, Horizontal FOV:78°, Vertical FOV:43°, Diagonal FOV:93°
Lens Mount L30: M12
Iris Type Fixed
Aperture F2.0

Pixel Density
OODPCVS 2 mm：Overview: 56.8 m, Outline: 28.4 m, Discern: 14.2 m, Perceive: 9.1 m, Characterize: 4.5 m, Validate: 2.3 m, Scrutinize: 0.8 m. 2.8 mm：Overview: 74.8 m, Outline: 37.4 m, Discern: 18.7 m, Perceive: 12 m, Characterize: 6 m, Validate: 3 m, Scrutinize: 1 m. 4 mm：Overview: 99.5 m, Outline: 49.8 m, Discern: 24.9 m, Perceive: 15.9 m, Characterize: 8 m, Validate: 4 m, Scrutinize: 1.3 m. The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN 62676-4: 2025 standard. IEC 62676-4:2025 describes the planning, design, installation, testing, commissioning, and maintaining of video surveillance systems (VSS) comprising image capture device(s), interconnection(s) and image handling device(s), for use in security applications within private or public spaces.

HEOP
Open Resources Memory: 150 MB, Smart RAM: 2150 MB, eMMC: 1 GB
Computing Power 4 TOPS
Open Capability NA
Deep Learning Structure Caffe,PyTorch,TensorFlow
Programming Language C,C++

AI Open Platform
Model Specification 1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model). 2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification). (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. (2) Classification: Region exception status detection, full analysis rule. (3) Mixed: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule; area overlap ratio counting, area overlap ratio exception detection. (4) Picture Comparison: Area status change detection. (5) OCR: OCR-triggered capture. (6) OVD: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. 3. Supports 4 model packages, each capable of detecting 16 target types and classifying 4 targets. The targets can be classified as 64 types. The device runs only 1 model at the same time. 4. Built-in models for PPE detection (hard hat and reflective clothing).

Video
Main Stream 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression Main stream: H.264/H.265+/H.264+/H.265, Sub-stream: H.264/MJPEG/H.265, Third stream: H.264/H.265
H.264 Type Baseline Profile,Main Profile,High Profile
H.265 Type Main Profile
Bit Rate Control CBR,VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 8 fixed regions for each stream
Target Cropping Yes

Audio
Audio Type Mono sound
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering Yes

Network
Protocols WebSockets,NTP,DHCP,WebSocket,UDP,RTSP,ICMP,IPv6,TCP/IP,IGMP,QoS,HTTPS,IPv4,HTTP,SSL/TLS,DNS,FTP,SFTP,RTP
Simultaneous Live View Up to 20 channels
API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP, EZVIZ
User/Host Up to 32 users 3 user levels: administrator, operator, and user
Network Storage NAS (NFS, SMB/CIFS)
Client iVMS-4200,Hik-Connect
Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Web Browser Plug-in required live view: IE11, Plug-in free live view: Safari 12+, Local service: Chrome 57.0+, Firefox 52.0+

Wi-Fi
Encryption Mode With -W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK, WPS
Wi-Fi Protocol With -W: IEEE802.11a,IEEE802.11b,IEEE802.11ax,IEEE802.11g,IEEE802.11n,IEEE802.11ac
Frequency Range With -W: 2.4 GHz to 2.4835 GHz；5.150 GHz to 5.850 GHz；
Channel Bandwidth With -W: 20MHz,40MHz

Image Parameters Switch Yes
Image Settings gain,saturation,brightness,sharpness,white balance,contrast,adjustable by client software or web browser
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement BLC,HLC,3D DNR
Privacy Mask Yes
Picture Overlay LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Interface
Ethernet Interface 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Video Output 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1024 GB
Audio 1 input (line in), 1 output (line out)
Alarm 2 input, 1 output (max. 12 VDC, 30 mA)
RS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key Yes
Power Output 12 VDC, max. 100 mA

Event
Basic Event Motion detection
Smart Event Scene change detection,audio exception detection,defocus detection, Face detection
Linkage audible warning,Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function
Face Capture Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second, Supports swing left and right from -70° to 70°, tilt up and down from -50° to 50°, Uploads face with background and closed-up face pictures, Supports best shot and quick shot for capture mode, Supports dynamic mosaic mask, Gets 7 face features
Face Comparison Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption
People Counting Supports Multi-Dimension People Counting, Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.), Supports real-time uploading and uploading by statistic cycle, Supports generating daily, weekly, monthly or annually reports, Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval, Supports face feature deduplication, Supports people flow data replenishment, Reverse counting alarm will be triggered when the target leaves the detection area in the direction opposite to the set direction
Queue Management Supports up to 8 detection regions, and independent arming schedule and linkage method Supports 2 detection modes: regional people queuing-up, waiting time detection Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue Supports raw data export for further analysis Supports real-time data uploading and scheduled data uploading Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold Waiting time detection: supports 1 alarm trigger condition, including greater than threshold Supports combined rule settings for Regional People Counting and Waiting Time Detection. Mode 1: Alarm can be independently triggered if any one of the event alarm conditions is met. Mode 2: Alarm can be triggered only when the number of people meets the alarm threshold and at least one person's waiting time meets the threshold.
Gaze Detection Max. detection distance: 5 m, Max. detection target number: 30, Supports 1 rule area(s), Supports 4 shield region(s)

General
Power 12 VDC ± 20%, 0.92 A, max. 11 W, PoE: IEEE 802.3af, Class 3, max. 12.9 W
Material Main body: Aluminum Alloy
Dimension 135 mm × 108 mm × 30.4 mm (5.32" × 4.25" × 1.2")
Package Dimension 252 mm × 160 mm × 95 mm (9.92" × 6.3" × 3.74")
Approx. 460 g (1.01 lb.)
With Package Weight Approx. 1100 g (2.43 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Heartbeat,mirror,password protection,one-key reset
Length of Lens Cable 2 and 8 m (6.6 and 26.2 ft.)

Approval
EMC FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

กล้อง

Image Sensor

1/2.7" Progressive Scan CMOS

Max. Resolution

2688 × 1520

Min. Illumination

Color: 0.005 Lux @ (F1.2, AGC ON)

Shutter Time

1 s to 1/100,000 s

Lens

Focal Length & FOV

L30 model: 2 mm, Horizontal FOV:128°, Vertical FOV:75°, Diagonal FOV:147° 2.8 mm, Horizontal FOV:104°, Vertical FOV:58°, Diagonal FOV:122° 4 mm, Horizontal FOV:78°, Vertical FOV:43°, Diagonal FOV:93°

Lens Mount

L30: M12

Iris Type

Fixed

Aperture

F2.0

Pixel Density

OODPCVS

2 mm：Overview: 56.8 m, Outline: 28.4 m, Discern: 14.2 m, Perceive: 9.1 m, Characterize: 4.5 m, Validate: 2.3 m, Scrutinize: 0.8 m. 2.8 mm：Overview: 74.8 m, Outline: 37.4 m, Discern: 18.7 m, Perceive: 12 m, Characterize: 6 m, Validate: 3 m, Scrutinize: 1 m. 4 mm：Overview: 99.5 m, Outline: 49.8 m, Discern: 24.9 m, Perceive: 15.9 m, Characterize: 8 m, Validate: 4 m, Scrutinize: 1.3 m. The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN 62676-4: 2025 standard. IEC 62676-4:2025 describes the planning, design, installation, testing, commissioning, and maintaining of video surveillance systems (VSS) comprising image capture device(s), interconnection(s) and image handling device(s), for use in security applications within private or public spaces.

HEOP

Open Resources

Memory: 150 MB, Smart RAM: 2150 MB, eMMC: 1 GB

Computing Power

4 TOPS

Open Capability

Deep Learning Structure

Caffe,PyTorch,TensorFlow

Programming Language

C,C++

AI Open Platform

Model Specification

1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model). 2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification). (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. (2) Classification: Region exception status detection, full analysis rule. (3) Mixed: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule; area overlap ratio counting, area overlap ratio exception detection. (4) Picture Comparison: Area status change detection. (5) OCR: OCR-triggered capture. (6) OVD: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. 3. Supports 4 model packages, each capable of detecting 16 target types and classifying 4 targets. The targets can be classified as 64 types. The device runs only 1 model at the same time. 4. Built-in models for PPE detection (hard hat and reflective clothing).

Video

Main Stream

50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

Video Compression

Main stream: H.264/H.265+/H.264+/H.265, Sub-stream: H.264/MJPEG/H.265, Third stream: H.264/H.265

H.264 Type

Baseline Profile,Main Profile,High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR,VBR

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Region of Interest (ROI)

8 fixed regions for each stream

Target Cropping

Yes

Audio

Audio Type

Mono sound

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3

Audio Bit Rate

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)

Audio Sampling Rate

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Environment Noise Filtering

Yes

Network

Protocols

WebSockets,NTP,DHCP,WebSocket,UDP,RTSP,ICMP,IPv6,TCP/IP,IGMP,QoS,HTTPS,IPv4,HTTP,SSL/TLS,DNS,FTP,SFTP,RTP

Simultaneous Live View

Up to 20 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP, EZVIZ

User/Host

Up to 32 users 3 user levels: administrator, operator, and user

Network Storage

NAS (NFS, SMB/CIFS)

Client

iVMS-4200,Hik-Connect

Security

Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

Web Browser

Plug-in required live view: IE11, Plug-in free live view: Safari 12+, Local service: Chrome 57.0+, Firefox 52.0+

Wi-Fi

Encryption Mode

With -W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK, WPS

Wi-Fi Protocol

With -W: IEEE802.11a,IEEE802.11b,IEEE802.11ax,IEEE802.11g,IEEE802.11n,IEEE802.11ac

Frequency Range

With -W: 2.4 GHz to 2.4835 GHz；5.150 GHz to 5.850 GHz；

Channel Bandwidth

With -W: 20MHz,40MHz


Image Parameters Switch

Yes

Image Settings

gain,saturation,brightness,sharpness,white balance,contrast,adjustable by client software or web browser

Wide Dynamic Range (WDR)

Digital WDR

Image Enhancement

BLC,HLC,3D DNR

Privacy Mask

Yes

Picture Overlay

LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Interface

Ethernet Interface

1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port

Video Output

1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1024 GB

Audio

1 input (line in), 1 output (line out)

Alarm

2 input, 1 output (max. 12 VDC, 30 mA)

RS-485

1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

Reset Key

Yes

Power Output

12 VDC, max. 100 mA

Event

Basic Event

Motion detection

Smart Event

Scene change detection,audio exception detection,defocus detection, Face detection

Linkage

audible warning,Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function

Face Capture

Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second, Supports swing left and right from -70° to 70°, tilt up and down from -50° to 50°, Uploads face with background and closed-up face pictures, Supports best shot and quick shot for capture mode, Supports dynamic mosaic mask, Gets 7 face features

Face Comparison

Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption

People Counting

Supports Multi-Dimension People Counting, Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.), Supports real-time uploading and uploading by statistic cycle, Supports generating daily, weekly, monthly or annually reports, Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval, Supports face feature deduplication, Supports people flow data replenishment, Reverse counting alarm will be triggered when the target leaves the detection area in the direction opposite to the set direction

Queue Management

Supports up to 8 detection regions, and independent arming schedule and linkage method Supports 2 detection modes: regional people queuing-up, waiting time detection Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue Supports raw data export for further analysis Supports real-time data uploading and scheduled data uploading Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold Waiting time detection: supports 1 alarm trigger condition, including greater than threshold Supports combined rule settings for Regional People Counting and Waiting Time Detection. Mode 1: Alarm can be independently triggered if any one of the event alarm conditions is met. Mode 2: Alarm can be triggered only when the number of people meets the alarm threshold and at least one person's waiting time meets the threshold.

Gaze Detection

Max. detection distance: 5 m, Max. detection target number: 30, Supports 1 rule area(s), Supports 4 shield region(s)

General

Power

12 VDC ± 20%, 0.92 A, max. 11 W, PoE: IEEE 802.3af, Class 3, max. 12.9 W

Material

Main body: Aluminum Alloy

Dimension

135 mm × 108 mm × 30.4 mm (5.32" × 4.25" × 1.2")

Package Dimension

252 mm × 160 mm × 95 mm (9.92" × 6.3" × 3.74")

Approx. 460 g (1.01 lb.)

With Package Weight

Approx. 1100 g (2.43 lb.)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language

33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

General Function

Heartbeat,mirror,password protection,one-key reset

Length of Lens Cable

2 and 8 m (6.6 and 26.2 ft.)

Approval

EMC

FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015

Safety

CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1

Environment

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Technical documents

Data Sheet

Quick Start Guide

User Manual

Dimensions

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware_V5.9.0_260723

Applied to:

DS-2CD6445G3-C2W

กล้อง
Image Sensor 1/2.7" Progressive Scan CMOS
Max. Resolution 2688 × 1520
Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON)
Shutter Time 1 s to 1/100,000 s

Lens
Focal Length & FOV L30 model: 2 mm, Horizontal FOV:128°, Vertical FOV:75°, Diagonal FOV:147° 2.8 mm, Horizontal FOV:104°, Vertical FOV:58°, Diagonal FOV:122° 4 mm, Horizontal FOV:78°, Vertical FOV:43°, Diagonal FOV:93°
Lens Mount L30: M12
Iris Type Fixed
Aperture F2.0

Pixel Density
OODPCVS 2 mm：Overview: 56.8 m, Outline: 28.4 m, Discern: 14.2 m, Perceive: 9.1 m, Characterize: 4.5 m, Validate: 2.3 m, Scrutinize: 0.8 m. 2.8 mm：Overview: 74.8 m, Outline: 37.4 m, Discern: 18.7 m, Perceive: 12 m, Characterize: 6 m, Validate: 3 m, Scrutinize: 1 m. 4 mm：Overview: 99.5 m, Outline: 49.8 m, Discern: 24.9 m, Perceive: 15.9 m, Characterize: 8 m, Validate: 4 m, Scrutinize: 1.3 m. The OODPCVS values are calculated using pixel densities for different use cases as recommended by the IEC/EN 62676-4: 2025 standard. IEC 62676-4:2025 describes the planning, design, installation, testing, commissioning, and maintaining of video surveillance systems (VSS) comprising image capture device(s), interconnection(s) and image handling device(s), for use in security applications within private or public spaces.

HEOP
Open Resources Memory: 150 MB, Smart RAM: 2150 MB, eMMC: 1 GB
Computing Power 4 TOPS
Open Capability NA
Deep Learning Structure Caffe,PyTorch,TensorFlow
Programming Language C,C++

AI Open Platform
Model Specification 1. Up to 3 models. Model type: detection model, classification model, mixed model (detection model and classification model). 2. Supports video analysis (detection, classification, mixed, OCR, segmentation, comparison) and scheduled capture analysis (classification). (1) Detection: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. (2) Classification: Region exception status detection, full analysis rule. (3) Mixed: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule; area overlap ratio counting, area overlap ratio exception detection. (4) Picture Comparison: Area status change detection. (5) OCR: OCR-triggered capture. (6) OVD: Region target exception status detection, line crossing target detection, line crossing target counting, region target number counting, full analysis rule, combined rule, area overlap ratio counting, area overlap ratio exception detection. 3. Supports 4 model packages, each capable of detecting 16 target types and classifying 4 targets. The targets can be classified as 64 types. The device runs only 1 model at the same time. 4. Built-in models for PPE detection (hard hat and reflective clothing).

Video
Main Stream 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)
Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Video Compression Main stream: H.264/H.265+/H.264+/H.265, Sub-stream: H.264/MJPEG/H.265, Third stream: H.264/H.265
H.264 Type Baseline Profile,Main Profile,High Profile
H.265 Type Main Profile
Bit Rate Control CBR,VBR
Scalable Video Coding (SVC) H.264 and H.265 encoding
Region of Interest (ROI) 8 fixed regions for each stream
Target Cropping Yes

Audio
Audio Type Mono sound
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Environment Noise Filtering Yes

Network
Protocols WebSockets,NTP,DHCP,WebSocket,UDP,RTSP,ICMP,IPv6,TCP/IP,IGMP,QoS,HTTPS,IPv4,HTTP,SSL/TLS,DNS,FTP,SFTP,RTP
Simultaneous Live View Up to 20 channels
API Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP, EZVIZ
User/Host Up to 32 users 3 user levels: administrator, operator, and user
Network Storage NAS (NFS, SMB/CIFS)
Client iVMS-4200,Hik-Connect
Security Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
Web Browser Plug-in required live view: IE11, Plug-in free live view: Safari 12+, Local service: Chrome 57.0+, Firefox 52.0+

Wi-Fi
Encryption Mode With -W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK, WPS
Wi-Fi Protocol With -W: IEEE802.11a,IEEE802.11b,IEEE802.11ax,IEEE802.11g,IEEE802.11n,IEEE802.11ac
Frequency Range With -W: 2.4 GHz to 2.4835 GHz；5.150 GHz to 5.850 GHz；
Channel Bandwidth With -W: 20MHz,40MHz

Image Parameters Switch Yes
Image Settings gain,saturation,brightness,sharpness,white balance,contrast,adjustable by client software or web browser
Wide Dynamic Range (WDR) Digital WDR
Image Enhancement BLC,HLC,3D DNR
Privacy Mask Yes
Picture Overlay LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Interface
Ethernet Interface 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port
Video Output 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)
On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1024 GB
Audio 1 input (line in), 1 output (line out)
Alarm 2 input, 1 output (max. 12 VDC, 30 mA)
RS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key Yes
Power Output 12 VDC, max. 100 mA

Event
Basic Event Motion detection
Smart Event Scene change detection,audio exception detection,defocus detection, Face detection
Linkage audible warning,Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function
Face Capture Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second, Supports swing left and right from -70° to 70°, tilt up and down from -50° to 50°, Uploads face with background and closed-up face pictures, Supports best shot and quick shot for capture mode, Supports dynamic mosaic mask, Gets 7 face features
Face Comparison Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption
People Counting Supports Multi-Dimension People Counting, Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.), Supports real-time uploading and uploading by statistic cycle, Supports generating daily, weekly, monthly or annually reports, Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval, Supports face feature deduplication, Supports people flow data replenishment, Reverse counting alarm will be triggered when the target leaves the detection area in the direction opposite to the set direction
Queue Management Supports up to 8 detection regions, and independent arming schedule and linkage method Supports 2 detection modes: regional people queuing-up, waiting time detection Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue Supports raw data export for further analysis Supports real-time data uploading and scheduled data uploading Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold Waiting time detection: supports 1 alarm trigger condition, including greater than threshold Supports combined rule settings for Regional People Counting and Waiting Time Detection. Mode 1: Alarm can be independently triggered if any one of the event alarm conditions is met. Mode 2: Alarm can be triggered only when the number of people meets the alarm threshold and at least one person's waiting time meets the threshold.
Gaze Detection Max. detection distance: 5 m, Max. detection target number: 30, Supports 1 rule area(s), Supports 4 shield region(s)

General
Power 12 VDC ± 20%, 0.92 A, max. 11 W, PoE: IEEE 802.3af, Class 3, max. 12.9 W
Material Main body: Aluminum Alloy
Dimension 135 mm × 108 mm × 30.4 mm (5.32" × 4.25" × 1.2")
Package Dimension 252 mm × 160 mm × 95 mm (9.92" × 6.3" × 3.74")
Approx. 460 g (1.01 lb.)
With Package Weight Approx. 1100 g (2.43 lb.)
Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Language 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
General Function Heartbeat,mirror,password protection,one-key reset
Length of Lens Cable 2 and 8 m (6.6 and 26.2 ft.)

Approval
EMC FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015
Safety CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1
Environment CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

กล้อง

Image Sensor

1/2.7" Progressive Scan CMOS

Max. Resolution

2688 × 1520

Min. Illumination

Color: 0.005 Lux @ (F1.2, AGC ON)

Shutter Time

1 s to 1/100,000 s

Lens

Focal Length & FOV

Lens Mount

L30: M12

Iris Type

Fixed

Aperture

F2.0

Pixel Density

OODPCVS

HEOP

Open Resources

Memory: 150 MB, Smart RAM: 2150 MB, eMMC: 1 GB

Computing Power

4 TOPS

Open Capability

Deep Learning Structure

Caffe,PyTorch,TensorFlow

Programming Language

C,C++

AI Open Platform

Model Specification

Video

Main Stream

50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

Sub-Stream

50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480)

Third Stream

50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

Video Compression

Main stream: H.264/H.265+/H.264+/H.265, Sub-stream: H.264/MJPEG/H.265, Third stream: H.264/H.265

H.264 Type

Baseline Profile,Main Profile,High Profile

H.265 Type

Main Profile

Bit Rate Control

CBR,VBR

Scalable Video Coding (SVC)

H.264 and H.265 encoding

Region of Interest (ROI)

8 fixed regions for each stream

Target Cropping

Yes

Audio

Audio Type

Mono sound

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3

Audio Bit Rate

64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)

Audio Sampling Rate

8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Environment Noise Filtering

Yes

Network

Protocols

WebSockets,NTP,DHCP,WebSocket,UDP,RTSP,ICMP,IPv6,TCP/IP,IGMP,QoS,HTTPS,IPv4,HTTP,SSL/TLS,DNS,FTP,SFTP,RTP

Simultaneous Live View

Up to 20 channels

API

Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP, EZVIZ

User/Host

Up to 32 users 3 user levels: administrator, operator, and user

Network Storage

NAS (NFS, SMB/CIFS)

Client

iVMS-4200,Hik-Connect

Security

Web Browser

Plug-in required live view: IE11, Plug-in free live view: Safari 12+, Local service: Chrome 57.0+, Firefox 52.0+

Wi-Fi

Encryption Mode

With -W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK, WPS

Wi-Fi Protocol

With -W: IEEE802.11a,IEEE802.11b,IEEE802.11ax,IEEE802.11g,IEEE802.11n,IEEE802.11ac

Frequency Range

With -W: 2.4 GHz to 2.4835 GHz；5.150 GHz to 5.850 GHz；

Channel Bandwidth

With -W: 20MHz,40MHz


Image Parameters Switch

Yes

Image Settings

gain,saturation,brightness,sharpness,white balance,contrast,adjustable by client software or web browser

Wide Dynamic Range (WDR)

Digital WDR

Image Enhancement

BLC,HLC,3D DNR

Privacy Mask

Yes

Picture Overlay

LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

Interface

Ethernet Interface

1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port

Video Output

1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging)

On-Board Storage

Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1024 GB

Audio

1 input (line in), 1 output (line out)

Alarm

2 input, 1 output (max. 12 VDC, 30 mA)

RS-485

1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

Reset Key

Yes

Power Output

12 VDC, max. 100 mA

Event

Basic Event

Motion detection

Smart Event

Scene change detection,audio exception detection,defocus detection, Face detection

Linkage

audible warning,Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

Deep Learning Function

Face Capture

Face Comparison

Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption

People Counting

Queue Management

Gaze Detection

Max. detection distance: 5 m, Max. detection target number: 30, Supports 1 rule area(s), Supports 4 shield region(s)

General

Power

12 VDC ± 20%, 0.92 A, max. 11 W, PoE: IEEE 802.3af, Class 3, max. 12.9 W

Material

Main body: Aluminum Alloy

Dimension

135 mm × 108 mm × 30.4 mm (5.32" × 4.25" × 1.2")

Package Dimension

252 mm × 160 mm × 95 mm (9.92" × 6.3" × 3.74")

Approx. 460 g (1.01 lb.)

With Package Weight

Approx. 1100 g (2.43 lb.)

Storage Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Language

General Function

Heartbeat,mirror,password protection,one-key reset

Length of Lens Cable

2 and 8 m (6.6 and 26.2 ft.)

Approval

EMC

Safety

CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1

Environment

CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006

Technical documents

Data Sheet

Quick Start Guide

User Manual

Dimensions

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware

For better user experience, we highly recommend you to update your device to the latest firmware asap.

Firmware_V5.9.0_260723

Applied to:

DS-2CD6445G3-C2

ติดต่อเรา

Hik-Partner Pro

Security Business Assistant. At Your Fingertips. Learn more

Scan and download the app

Download

Hik-Partner Pro

Get a better browsing experience

You are using a web browser we don’t support. Please try one of the following options to have a better experience of our web content.
