AcuSeek NEW HOT
NEW
add compare icon

DeepinMind AIOP NVS

  • Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080P decoding capacity
  • H.265+/H.265/H.264+/H.264 video formats
  • Up to 32-ch IP cameras can be connected
  • Deep learning based video analytics for not wearing hard hat detection and event detection, including people running detection, people gathering detection, violent motion detection, using mobile phone detection, etc

View Less
View more
Data Sheet
Sales Inquiry

Available models:

iDS-6732NXI-M1/AF(1×2T)
View more View Less
iDS-6732NXI-M1/AF NEW
Data Sheet

Specification

  • AI Open Platform Performance
  • Engine3 * KT5，2 for small model analysis as default , 1 for lager model algorithm secondary analysis,1 engine can support 4 algorithm models at the same time
  • Live Video Analysis1 engine can support up to 8ch,(8ch@4MP，4ch @8MP)
  • Auto-Switch Video Analysis1 engine can support up to 16ch,(switch time between 10 to 3600 seconds)
  • Scheduled Capture Analysis1 engine can support up to 16ch, (switch time between 3 to 3600 seconds)
  • Offline Picture Analysis4 images per GPU per second or 1 image per GPU per second ( Large model)
  • Human
  • Facial recognitionFace Capture/Face Picture Comparison(32 face libraries, 100, 000 pictures)
  • Personnel ComplianceHard Hat/Reflective Cloth/Skin Exposure/Goggles/Smoking/Phone Call/Using Phone/Sleeping (Face down)/Sleeping (Reclining)/Absence/Seatbelt/Person Overstay/Person Loitering
  • Workwear Registration and ComparisonWork uniform/Work hat
  • People CountingRegional people counting/People counting statistics
  • Street BehaviourViolent/Fall Down/Running/Gathering
  • Vehicle
  • Vehicle RecognitionExcavator/Bulldozer/Dump Truck/Concrete Pump Truck/Crane/Cement Tanker/Tower Crane/Truck/Oil Tank Truck/Electric Moped/Bicycle/Coach/Small Sized Vehicle/Forklift/Tricycle
  • Environment
  • Smoke and FireSmoke/Fire
  • Perimeter ProtectionIntrusion detection/Line crossing detection/Region entrance detection/Region exiting detection
  • Fire Escape Occupation DetectionFire_Escape_Occupation_Detection
  • Object
  • Object DetectionFire_Extinguisher/ Oxygen_Cylinder/ Acetylene_Cylinder/ Gas_Cylinder/ Fire_Extinguisher_Box/Fire_Blanket/ Banner/ Dustbin/Traffic_Cone
  • AIOP
  • AI Open Platform AlgorithmDetection model, Classification model, Mixed model (Detection model and Classification model), Double detection model
  • Video and Audio
  • IP Video Input32-ch
  • Incoming Bandwidth256 Mbps
  • Outgoing Bandwidth256 Mbps
  • Video Output ModeHDMI/VGA simultaneous output
  • HDMI OutputHDMI1：8K (7680 × 4320)/30 Hz, 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1080P (1920 × 1080)/60 Hz HDMI2：4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
  • VGA Output1080P (1920 × 1080)/60 Hz
  • Audio Output1-ch, RCA (Linear, 1 KΩ)
  • Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ)
  • Decoding
  • Decoding FormatH.265/H.265+/H.264/H.264+
  • Decoding CapabilityUp to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080P
  • Recording Resolution32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
  • Synchronous Playback16-ch
  • Network
  • Remote Connection128
  • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
  • APIONVIF (profile S/G); SDK; ISAPI
  • Compatible BrowserIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
  • Network Interface2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • Auxiliary Interface
  • SATA1 SATA interfaces
  • CapacityUp to 16 TB capacity for each HDD,1 built-in 3.5-inch 2 TB SATA hard disk
  • eSATA1 eSATA interface
  • Serial Interface1 RS-232 interface, 2 RS-485 interfaces
  • USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
  • Alarm In/Out16/4
  • General
  • GUI LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
  • Power Supply12V DC, 12.5A
  • Consumption≤ 90 W(without HDD)
  • Working Temperature-10℃ to 55℃ (14℉ to 131℉)
  • Working Humidity10% to 90%
  • Dimension (W × D × H)320 mm × 224 mm × 65 mm
  • ≤ 4 kg (without HDD)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

AI Open Platform Performance
Engine
3 * KT5，2 for small model analysis as default , 1 for lager model algorithm secondary analysis,1 engine can support 4 algorithm models at the same time
Live Video Analysis
1 engine can support up to 8ch,(8ch@4MP，4ch @8MP)
Auto-Switch Video Analysis
1 engine can support up to 16ch,(switch time between 10 to 3600 seconds)
Scheduled Capture Analysis
1 engine can support up to 16ch, (switch time between 3 to 3600 seconds)
Offline Picture Analysis
4 images per GPU per second or 1 image per GPU per second ( Large model)
Human
Facial recognition
Face Capture/Face Picture Comparison(32 face libraries, 100, 000 pictures)
Personnel Compliance
Hard Hat/Reflective Cloth/Skin Exposure/Goggles/Smoking/Phone Call/Using Phone/Sleeping (Face down)/Sleeping (Reclining)/Absence/Seatbelt/Person Overstay/Person Loitering
Workwear Registration and Comparison
Work uniform/Work hat
People Counting
Regional people counting/People counting statistics
Street Behaviour
Violent/Fall Down/Running/Gathering
Vehicle
Vehicle Recognition
Excavator/Bulldozer/Dump Truck/Concrete Pump Truck/Crane/Cement Tanker/Tower Crane/Truck/Oil Tank Truck/Electric Moped/Bicycle/Coach/Small Sized Vehicle/Forklift/Tricycle
Environment
Smoke and Fire
Smoke/Fire
Perimeter Protection
Intrusion detection/Line crossing detection/Region entrance detection/Region exiting detection
Fire Escape Occupation Detection
Fire_Escape_Occupation_Detection
Object
Object Detection
Fire_Extinguisher/ Oxygen_Cylinder/ Acetylene_Cylinder/ Gas_Cylinder/ Fire_Extinguisher_Box/Fire_Blanket/ Banner/ Dustbin/Traffic_Cone
AIOP
AI Open Platform Algorithm
Detection model, Classification model, Mixed model (Detection model and Classification model), Double detection model
Video and Audio
IP Video Input
32-ch
Incoming Bandwidth
256 Mbps
Outgoing Bandwidth
256 Mbps
Video Output Mode
HDMI/VGA simultaneous output
HDMI Output
HDMI1：8K (7680 × 4320)/30 Hz, 4K (3840 × 2160)/60 Hz, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1080P (1920 × 1080)/60 Hz HDMI2：4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.
VGA Output
1080P (1920 × 1080)/60 Hz
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Decoding
Decoding Format
H.265/H.265+/H.264/H.264+
Decoding Capability
Up to 2-ch@32 MP/2-ch@24 MP/4-ch@12 MP/8-ch@8 MP/16-ch@4 MP/32-ch@1080P
Recording Resolution
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF *: After ultra HD resolution mode is enabled, the NVR supports up to 8-ch 32 MP/24 MP IP video inputs.
Synchronous Playback
16-ch
Network
Remote Connection
128
Network Protocol
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
API
ONVIF (profile S/G); SDK; ISAPI
Compatible Browser
IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
Network Interface
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary Interface
SATA
1 SATA interfaces
Capacity
Up to 16 TB capacity for each HDD,1 built-in 3.5-inch 2 TB SATA hard disk
eSATA
1 eSATA interface
Serial Interface
1 RS-232 interface, 2 RS-485 interfaces
USB Interface
Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0
Alarm In/Out
16/4
General
GUI Language
English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
Power Supply
12V DC, 12.5A
Consumption
≤ 90 W(without HDD)
Working Temperature
-10℃ to 55℃ (14℉ to 131℉)
Working Humidity
10% to 90%
Dimension (W × D × H)
320 mm × 224 mm × 65 mm
≤ 4 kg (without HDD)
